检测开关
T5-1511SA

产品名称:贴片三脚检测开关

产品规格:6.35×3.5×3mm

声明:有关于产品的规格、参数、寿命、工作温度、手感、防水等级等数据,只代表内部的测试结果,如需详细参数请联系公司业务人员。

订购热线:18002870666


特性(Features)
◆ 轻动作力:最高40gf
  The SMT stroke is within 1.5mm.
 表面贴装为贴片型。
  The surface mount is of patch type.
◆ 适应回流焊接。
  Adapt to reflow soldering.
 开关可用于编带和卷轴包装。
  Switches can be used for braid and reel packaging.

用途(Applications
 检测插入各种媒体,鉴定录音带、录像机、录音机,检测录入式功能,医疗设备、汽车电器、蓝牙笔、美容仪器等。

Testing inserts all kinds of media, authenticating tapes, video recorders, tape recorders, testing input functions, medical equipment, automotive appliances, bluetooth pens, beauty instruments, etc.

电性(Electrical
◆ 额定电流(Rating): 10 mA 30 VDC
◆ 绝缘电阻(Insulation resistance):100mΩ min. 100V DC
◆ 介电强度(Dielectric strength): 100V AC for 1 min
◆ 接触电阻(Contact resistance): 200 mΩ max
◆ 温度范围(Temperature range): -20℃ to +70℃
◆ 寿命(Lifetime): 100,000 Cycles min
◆ 操作力(Operating force):50gf max
◆ 行程(Travel):0.3±0.1mm
